Specifications
| Item | Specifications | ||||
| Model | HUD-E703-50 | HUD-E703-100 | HUD-E703-150 | HUD-E703-200 | HUD-E703-300 |
| Test method | Pneumatic operated, 2 or 3 zone | ||||
| Basket internal dimension | 350W*400D*350Hmm (50L) | 500W*450D*450Hmm (100L) | 550W*450D*550Hmm (150L) | 650W*450D*670Hmm (200L) | 800W*450D*820Hmm (300L) |
| External chamber dimension | 1230Wx1830Dx1270Hmm | 1380Wx1980Dx1370Hmm | 1420Wx2000Dx1400Hmm | 1530Wx1980Dx1590Hmm | 1680Wx1980Dx1735Hmm |
| High temperature chamber preheating range | Ambient to +160℃,<35min | ||||
| Low temperature chamber precooling range | Ambient to -50℃,<70min | ||||
| Test temperature | -40 to +150℃ | ||||
| Temperature deviation | 3~5℃ | ||||
| Lifting switch time | ≤10 seconds | ||||
| Test duration | >30mins in high temperature chamber / low temperature chamber | ||||
| Test hole for cable routing | Diameter 50mm on the left of chamber attach a silicone plug | ||||
| External chamber material | High quality electrolytic steel plate spray with powder, antirust | ||||
| Internal material | SUS#304 stainless steel | ||||
| Thermal insulation material | High quality superfine glass fiber | ||||
| Refrigerant | R404A / R23 | ||||
| Cooling method | Water cooling | ||||
| Power supply | Three phase, 380V, 50Hz | ||||
